Venetian Style Fire Shutters
Ottawa Fire Safety is proud to provide & install Residential Fire Shutters.
To be as non-invasive as possible is our goal when installing fire rated closures for residential windows.
Venetian Shutters make achieving this goal possible in the most efficient and economic way.
Ideal Applications
Venetian window fire shutters are designed with the goal to be installed within an existing window opening. This makes their aesthetic seamless and non-invasive.
Perfect for residential or commercial installation where looking good is priority.
These are typically used in these situations:
-
Protecting Fire Escape Stairs
-
Protecting Refuge Balconies
-
Protecting Tenant Evacuation Routes
-
Protecting Neighboring Buildings
Fire Ratings
Venetian fire shutters are rated for 45 minutes and are CAN/ULC S104 compliant.
Every product is provided with a ULC certification tag and is Ontario Building & Fire Code compliant.
Sizing
Minimum size: 12" wide x 12" high
Maximum size: 42" wide x 60" high
In the case where your needs are under the minimum or over the maximum, we can provide alternatives methods.
Fire Shutters for Residential Windows
How they work
Fusible link
The fusible link is a heat-sensitive device that holds the fire shutter in the open position. It is typically made of a metal alloy that melts at a specific temperature.
Testing / maintenance
Regular testing and maintenance of the entire system is crucial to ensure proper functionality during an emergency.
Activation
When a fire occurs, the heat from the flames causes the fusible link to melt. Once it melts, it releases the mechanism that holds the shutter open, allowing it to close automatically.
Closure
The closing of the shutter creates a barrier that helps contain the fire and smoke, protecting other areas of the building.
-
Higher Fire Rating
-
Ideal for Large / Unique Openings
-
Motorized / non motorized options
-
Canadian Made
-
ULC Certified
What does a fusible link look like?
Our client was faced with a fire emergency. The presence of a F/R closure significantly reduced the blaze's potential damage and saved lives.
